PROLiNK PRO733100L Online UPS Tower - 3P/3P 100kVA

SKU : -

Harga : Call

Dapatkan harga terbaik Kami

INPUT - Rated voltage : 3 x 400V (3Ph + N) - Voltage tolerance : LV.- 3x200 to 3x230 V to HV.- 3x380 to 3x415 V - Rated frequency : 50Hz/60Hz 5.0 Hz (default value) - Power factor / THDI : 1 / < 1.5% OUTPUT - Rated voltage : 3Ph + N: 400 V (can be configured 380 / 400 / 415 VAC) - Voltage tolerance : static reguation load ±0.5 % - Rated frequency : 50 / 60 Hz - Frequency tolerance : ±0.05% - Overload : 1) 100~112.5%: 10 mins. 2) 112.5~122%: 5 mins. 3) 122~135%: 1min. 4) >135%: immediate - Crest factor : 3.2 : 1 BYPASS - Rated voltage : rated output voltage - Voltage tolerance : 12%, -15% (configurable with from 5% to 25%) - Rated frequency : 50/60 Hz - Frequency tolerance : 5.0 Hz (default value,configurable) EFFICIENCY - Online mode @ 100 % of load : up to 96.4% STANDARDS - Safety : Safety : EN62040?1-1 - EMC : EN 62040?2 , EN61000-1 - Performance : EN 62040?3

Brand :

prolink

Capacity :

100kVA / 90kW

Waktu cadangan baterai :

Depend on load

Waktu pemindahan :

0ms

Battery capacity :

65Ah x 62

Waktu pengisian baterai :

4 Jam
